Marushichi Co.
Marushichi Tablet Machine
Manufacturer: Marushichi Co., Ltd.
Features
You can run the machine continuously without an operator. Moreover, it can keep working for long periods.
You can easily adjust the pressure, and as a result, set the firmness to the best level.
In addition, you can form the material into square tablets.
When you connect a hopper loader, the system supports long, unmanned operation. This way, you maintain productivity without manual work.
Specifications
| Item | MTH-15 | MTH-30 | MTHL-30 | MTH-40 | MTHL-40 | MTH-80 |
|---|---|---|---|---|---|---|
| Pressing force (kN) | 150 | 300 | 300 | 400 | 400 | 800 |
| Filling depth (mm) | 60 | 80 | 80 | 100 | 100 | 100 |
| Max punch diameter (mm) | Φ40 | Φ60 | Φ60 | Φ80 | Φ80 | Φ80 |
| Max molding weight (g) | 45 | 160 | 240 | 420 | 670 | 670 |
| Hopper capacity (L) | 4 | 6 | 6 | 10 | 10 | 10 |
| Motor (kW) | 5.5 | 7.5 | 7.5 | 11 | 11 | 15 |
| Oil tank capacity (L) | 100 | 150 | 180 | 200 | 240 | 240 |
| Machine weight (kg) | 600 | 1100 | 1180 | 1600 | 1700 | 3500 |
