Mikuni Engineering Co.
Mikuni PHNL-226H Vacuum Pump
Manufacturer: Mikuni Engineering Co., Ltd.
Model: PHNL-226H
Features
- This is suitable for use in approximately 96 – 98% ultimate vacuum.
- This has been used for distillation, drying, extraction and filtration in chemical and many other industries.
- This is designed based on the technology of reciprocating compressor and has an excellent performance.
- Oil-free type (PHNL Series) is also available with many experiences.
Specifications
| Cylinder Bore | 360 – 780mm |
|---|---|
| Stroke | 130 – 230mm |
| Piston Displacement | 11.8 – 71.2m3/min |
| Ultimate Vacuum | 96 – 98% |
| Req. Power | 45kW |
