- Check the VT secondary voltage non-contact through the wire sheath.
- Prevent damage to the built-in VT, which lacks a fuse or other protection device, in case of a short circuit in the clip of the test device.
- Detect the voltage, which triggers the signal output (contact).
- The operation lamp flashes to indicate detection.
Specifications
| Voltage Sensing Range | AC Approx. 40~240V (50/60Hz) |
|---|---|
| Reaction time (ON) | Within 20ms (time from voltage detection to signal output (contact) turned on) |
| Reaction time (OFF) | Within 30ms (time from no-voltage detection to signal output (contact) OFF) |
| Display & Signal Output | When the voltage is detected, the operating light flashes and the signal output (contact) is turned on |
| Output contact capacity | AC/DC 220V, 0.5A, A contact, ON resistance approx. 3Ω |
| Operating Circuit Voltage | AC 500V or less |
| power | AA alkaline batteries×2 |
| Dimensions and Weight | W76×H135×D30mm approx. 220g |
| accessory | Battery, dedicated non-contact sensor (PS-240), special case |
