- Solar panels can be accurately measured even when power is being generated.
- Safe operation without the need to short-circuit the P-N phase.
- Can be used in AC circuits.
- Can also function as a 500V/1000V megger, similar to conventional megger devices.
Specifications
| Rated Measurement Voltage | PVL（500V） | PVH（1000V） |
|---|---|---|
| Maximum effective display value | 100MΩ | 2000MΩ |
| Median display | 2MΩ | 50MΩ |
| First effective measurement range | 0.1MΩ or more and 50MΩ | 2MΩ or more and 1000MΩ |
| Tolerance | ± 5% RDG or less | |
| 2nd effective measurement range | 0.05MΩ～0.1MΩ | 1MΩ～2MΩ |
| 50MΩ～100MΩ | 1000MΩ～2000MΩ | |
| Tolerance | ± 10% RDG or less | |
| indication | 3200 count LCD and bar graph display |
|---|---|
| Viewing range | 3. 200MΩ / 32.00MΩ / 320.0MΩ / 3200MΩ (4 Range Auto) |
| Minimum resolution | 0.001MΩ |
| Other features | Overrange display, data hold, auto power off, backlight, automatic load discharge function |
| standard | JIS C 1302(2002) compliant |
| Operating temperature and humidity range | 0~40°C, 80%RH or less (no condensation) |
| power | AA alkaline battery×6 |
| Dimensions and Weight | W170×H52×D105mm Approx. 350g |
| accessory | Battery, measuring cord set, insulating cap (red), belt, cord storage case |
| option | Probe with switch (cord length approx. 1m) (MP-001) ¥3,200 (excluding tax) Capacitive countermeasure cord (MC-001) ¥5,400 (excluding tax) |
