Multi MSEI-200C 1000V Compatible Solar Power Generation Equipment DC Circuit Insulation Diagnostic Equipment
Manufacturer: Multi Measuring Instruments Co., Ltd.
Model: MSEI-200C
Features
・Compatible with solar power generation equipment up to 1000V
・Accurate insulation resistance measurement is possible even during power generation
・Section determination of insulation degradation
is possible ・No need to remove surge absorbers, etc.
・Ungrounded circuits do not need to be disconnected from the power conditioner
・(Ichisai) Obtained a joint patent with the Chubu Electric Safety Association
Specifications
| Measurement Items | Generator voltage Insulation resistance (P-phase/N-phase/PN-phase/module-to-module) |
|---|---|
| Measuring range | Generator Voltage: DC 0.01V~999.9V Isolation Resistance: 0.01MΩ~19.99MΩ |
| Generating voltage accuracy | ±1%rdg±10dgt |
| Insulation resistance accuracy | 0.01MΩ～10MΩ：±5%rdg 10.01MΩ～19.99MΩ：±10%rdg |
| Good or bad judgment | Red LED (No Good) flashes when the insulation resistance value is less than 1MΩ If there is no problem with the insulation resistance value, the green LED (Good) lights up |
| Measurement time setting | 30/180/300/600/900sec |
| Module Count Setting | 2～28 |
| Using a Circuit Circuit | DC 1000V Solar Power Circuit |
| Operating temperature and humidity range | 0°C~50°C 85%RH or less (non-condensation) |
| power | AA alkaline batteries×4 or AC adapter (optional) |
| Dimensions and Weight | W190×H140×D42mm approx. 600g |
| accessory | Batteries, voltage acquisition cordsets, carrying cases |
| option | AC Adapter (MA-001) ¥5,400 (excluding tax) Voltage Intake Magnet Cord (MC-009) Open Price |
