Features

Resistant to sludge
Large diameter orifice (Φ5mm) makes it resistant to sludge and less likely to clog

High reliability
Uses a simple independent direct acting valve

Drain detection unit detects and discharges drain (FS type only) Reduces air loss

Alarm output (FS type only)
Alarm output when drain discharge is insufficient
(no voltage, contacts close when alarm occurs)

Energy-saving model
Air loss is minimized by using a float sensor.ADE450
-A1-FS(-H): 100V specificationADE450
-A2-FS(-H): 200V specification
*-H is equipped with a freeze prevention heater.

Standard model
Large-diameter orifice prevents cloggingADE450
-A1(-H): 100V specificationADE450
-A2(-H): 200V specification
*-H comes with anti-freeze heater

Applications

Automatically drains water and oil
