Nakayama Co.,Ltd.
Nakayama Orther Materials And Tools
Manufacturer: Nakayama Co.,Ltd
PIN MARK / MINI PIN MARK
It is used by attaching it to a dieboard. We have two sizes.
| ITEM | REMARKS | MOQ |
|---|---|---|
| PIN MARK | A-Z,-,0-9 16X22 | 1(pc) |
| MINI PIN MARK | A-Z,-,0-9 9X15 | 1(pc) |
*The mini pin marks are available only by special order.
DOUBLE COATED TAPE
Double coated tape for securing paper on pressboard.
| ITEM | REMARKS | MOQ | CODE |
|---|---|---|---|
DOUBLE COATED TAPE | size: 50mmX30m | 1 (pc) | 610120 |
NT CUTTER
Box cutter used for cutting paper on pressboard.
Replacement blades are also available.
| ITEM | REMARKS | MOQ | CODE |
|---|---|---|---|
| NT CUTTER AND SPARE BLADES | main | 1 (pc) | 630201 |
| spare | 200 (pcs) | 630202 |
CUT RESISTANT GLOVE
This glove is made of cut-resistant fiber. It is convenient and safe when handling cutting rules.
| ITEM | REMARKS | MOQ | CODE |
|---|---|---|---|
| CUT RESISTANT GLOVE | size: M | 1 (set) | 691001 |
| size: L | 1 (set) | 691002 |
PRESSBOARD CUTTING RULER
Cutting ruler for cutting paper on pressboard. The channel width can be kept fixed width.
| ITEM | MOQ | CODE |
|---|---|---|
| PRESSBOARD CUTTING RULER | 1 (pc) | 632051 |
RULE PULLER
This nipper can pull out cutting rules in a dieboard.
Duck bill prevents damage to the cutting edge. We have two sizes, large and small.
| ITEM | REMARKS | MOQ | CODE |
|---|---|---|---|
| RULE PULLER | size: L | 1 (pc) | 632032 |
| size: M | 1 (pc) | 632031 |
SPACING WOOD
Wooden shim. It is used to adjust the gripper margin of dieboard.
| ITEM | REMARKS | MOQ | CODE | ||
|---|---|---|---|---|---|
| SPACING WOOD | Thickness: 0.7mm | Height: 18.0mm | size: 0.7mm T × 18.0mm H | 200 (pcs) | 608133 |
| Thickness: 0.9mm | Height: 18.0mm | size: 0.9mm T × 18.0mm H | 200 (pcs) | 608126 | |
| Thickness: 1.4mm | Height: 18.0mm | size: 1.4mm T × 18.0mm H | 100 (pcs) | 608132 | |
| Thickness: 1.8mm | Height: 18.0mm | size: 1.8mm T × 18.0mm H | 100 (pcs) | 608125 | |
| Thickness: 2.8mm | Height: 18.0mm | size: 2.8mm T × 18.0mm H | 50 (pcs) | 608131 | |
| Thickness: 3.7mm | Height: 18.0mm | size: 3.7mm T × 18.0mm H | 50 (pcs) | 608124 | |
| Thickness: 4.6mm | Height: 18.0mm | size: 4.6mm T × 18.0mm H | 40 (pcs) | 608111 | |
| Thickness: 5.5mm | Height: 18.0mm | size: 5.5mm T × 18.0mm H | 30 (pcs) | 608101 | |
SPACING RULES (IRON)
Iron shim.
| ITEM | REMARKS | MOQ | CODE | |
|---|---|---|---|---|
| SPACING RULES (IRON) | Thickness: 0.7mm | size: 0.7mm T × 18.0mm H × 909mm L | 60 | 347110 |
| Thickness: 0.9mm | size: 0.9mm T × 18.0mm H × 909mm L | 50 | 347120 | |
| Thickness: 1.4mm | size: 1.4mm T × 18.0mm H × 909mm L | 30 | 347130 | |
| Thickness: 1.8mm | size: 1.8mm T × 18.0mm H × 909mm L | 25 | 347140 | |
SPACING RULES
Shim made of carbon tool steel (SK grade).
| ITEM | REMARKS | MOQ | CODE | |
|---|---|---|---|---|
| SPACING RULES | Thickness: 0.25mm | size: 0.25mm T × 17.5mm H × 670mm L | 140 | 347052 |
| Thickness: 0.45mm | size: 0.45mm T × 17.5mm H × 670mm L | 80 | 347062 | |
RECYCLE MARK
It is mounted into dieboard and can process debossing at the same time while die cutting.
| ITEM | REMARKS | MOQ | CODE | |
|---|---|---|---|---|
| RECYCLE MARK | Height: 23.4mm | Base size: 9.7 × 9.7 mm | 1 (pc) | 608651 |
JIG SAW BLADES
Jig saw blades for a jig saw machine.
| ITEM | REMARKS | MOQ | CODE | |
|---|---|---|---|---|
| JIG SAW BLADES | Thickness: 0.7mm | 20×5 | 100 (pcs) | 622021 |
| Thickness: 0.7mm | 16×5 | 100 (pcs) | 622022 | |
| Thickness: 0.7mm | 16×3 | 100 (pcs) | 622023 | |
DRILLS FOR LEUTOR
It is used to make the kerf width of the plywood fixed width after laser cutting.
| ITEM | REMARKS | MOQ | CODE |
|---|---|---|---|
| LEUTOR | size: 0.7mmT | 10 (pcs) | 630300 |
| size: 0.72mmT | 10 (pcs) | 630301 | |
| size: 0.73mmT | 10 (pcs) | 630302 | |
| size: 0.75mmT | 10 (pcs) | 630304 | |
| size: 0.8mmT | 10 (pcs) | 630305 | |
| size: 0.9mmT | 10 (pcs) | 630306 | |
| size: 1.0mmT | 10 (pcs) | 630307 |
*We can also order other items not listed above, so please feel free to contact us.
HAMMER
Mallet for putting cutting rules into a dieboard.
A tip only is also available.
| ITEM | REMARKS | MOQ | CODE |
|---|---|---|---|
| Plastic Hammer | 1 (pc) | 634021 | |
| Wooden hammer – 48φ | main | 1 (pc) | 634031 |
| spare | 1 (pc) | 634032 | |
| Wooden hammer – 60φ | main | 1 (pc) | 634033 |
| spare | 1 (pc) | 634034 |
*Hammers are available only by special order.
