Manufacturer: Nikki Co., Ltd.
Model: NLLP Series

Features

It features large white lenses that are easy to see with both eyes, and is designed with magnifications of 1.75x and 2.25x.
LEDs are installed around the lens to brightly illuminate your hands. The LEDs reduce the glare and reflections, creating a gentle light that is less tiring on the eyes.
The LEDs used are from globally reliable manufacturers.

Ideal for visual inspection lighting

With a typical magnifying glass, each small LED is reflected on metal surfaces and other objects, causing them to appear granular.
Nikki’s LED magnifier emits uniform light, which is unlikely to cast shadows and does not reflect on the workpiece. It also does not produce stripes when photographing, making it the perfect LED magnifier for photographing inspection items.When photographing a metal surface with this product , the light is uniform and gentle, with no flickering or stripes.

Specification

Color Temperature	5,700K
Expected Life	Operating temperature 25℃ 60,000 hours *Life is the point at which the illuminance becomes 70% of the initial illuminance.
Operating temperature	-10℃～40℃
Power Consumption	7.5W / 8W / 12.5W
Lens	Optical white glass lens
Magnification	1.75x / 2.25x
Light source used	White LED
Dimming method	Stepless dimming (20-100%)
Input voltage	AC100-240V
Compliance standards	(adapter)

Accessories	Dedicated adapter (ND-PM246)

Comparison of optical white glass and blue glass

Cheap magnifying glasses generally contain blue glass, but this can cause the light to appear blue due to impurities.
Magnifying glasses that use this type of low-transparency blue glass make it difficult to see objects clearly.
Our LED magnifiers use highly transparent optical white glass (borosilicate glass), making them easy to see and less tiring on the eyes.
It has good visibility and makes workpieces and text easy to see.

Main Applications

Standard Model List

Model	Lens size	Magnification	Total luminous flux	Illuminance (distance)	Power Consumption	Ưeight	Fixing Method
NLLP50ST-3D	ø5″	1.75x	1,100lm	8,700 lx (20 cm)	7.5W	2.5kg	Tabletop
NLLP50ST-5D		2.25x		3,800 lx (30 cm)
NLLP60BT-3D	ø6″	1.75x	960lm	8,800 lx (20 cm)	8W	2.3kg	Clamp type, maximum width 60mm
NLLP60BT-5D		2.25x		3,900 lx (30 cm)
NLLP70BT-3D	7″ x 5.2″	1.75x	1,500lm	12,200 lx (20 cm)	12.5W	3.1 kg

Main dimensions

NLLP50ST

NLLP70BT

NLLP70BT
