NISSAN TANAKA AU150B-H12 II Pressure Regulator
Manufacturer: NISSAN TANAKA
Model: AU150B-H12 II
Features of AU150B-H12 II
Large flow rate of up to 150L/min (normal) can also be used for high-efficiency pumps.
With a wide variety of compatible gases, it can be used for high-purity gas supply lines and various other applications.
Even with high flow rates, it ensures a stable outlet pressure.
Easy to install in various places due to its compact size and lightweight
Specifications
| Item | Specification |
|---|---|
| Model | AU150B-H12 II |
| Gas Type | CO2 |
| Maximum Working Pressure (MPa) | Inlet: 25 / Outlet: 1 |
| Maximum Flow Rate (MPa) | Inlet: 12 / Outlet: 0.6 |
| Connection Type | Inlet: W22-14 Right-hand thread / Outlet: M12 x 1 Thread |
| Hose Diameter | Inside Diameter Ø8.5 Hose |
| Specification Item | Details |
|---|---|
| Fluid Name | Gas |
| Range | OUT side 40 ~ 150L/min (normal) |
| Maximum Working Pressure [MPa] | 0.6 |
| Operating Temperature Range [°C] | -5 ~ 40 |
| Material (Body) | C3771 |
| Connection Type | Screw type |
| Power Supply | AC100V, 900W |
| Power Cord Length [m] | 3 |
| Weight [kg] | 3.1 |
Kouei is Distributor/Agent of Nissan Tanaka
