Manufacturer: Okaya Seiritsu Engineering Co., Ltd.
Model: IGS
Features
- Traditional Strip Edge Detection in plating lines commonly used pneumatic sensing methods.
- IGS Sensor by EMG utilizes electromagnetic induction, providing high-precision detection unaffected by fumes, water droplets, scale, and other influences.
- Widely Adopted in plating lines with harsh environments due to its ability to deliver reliable results.
- Detection Accuracy of the IGS sensor is approximately ±1mm, ensuring high precision.
Specifications
| Type | IGS 1/40/120/50/01 |
|---|
| BMI2.11.1 | 110/120/220/230 V, 50/60 Hz |
|---|
| Power Supply Voltage | 60VA |
|---|
| Power Consumption | 0 |
|---|
| Instrument Ambient Temperature (Electronic Circuit) | 0 ～ 50 ℃ |
|---|
| Instrument Ambient Temperature (Fork Sensor) | 0 ～ 80 ℃ |
|---|
| Measurement Range | Approx. 40 mm |
|---|
| CAN OPEN Data Transmission | |
|---|
| Output Accuracy (when output is 4.5V) | Approx. ±1mm |
|---|
| When Measurement Conditions Are Constant | 10 msec. |
| Sensor Grade | IP 67 |
| BMI2.11.1 Protection Rating | IP 54 |
| Minimum Impact Distance from Sensor | 100 mm |
| Environmental Cable Length | 5 m |
| BMI2.11.1 Function | Refer to the BMI2.11.1 catalog |
