Sakaguchi Electric Heaters CO.
Sakaguchi Coates Heater
Manufacturer: Sakaguchi Electric Heaters CO., LTD.
Features
Specifications
| Model | Voltage (V) | Capacity (W) | Overall Length (LH) | Heating Length | Product Code |
|---|---|---|---|---|---|
| NSP01 NSP02 NSP03 NSP04 NSP05 | 100 100 200 100 200 | 350 500 500 750 750 | 220 225 225 270 270 | 130 155 155 200 200 | NSP1 NSP2 NSP3 NSP4 NSP5 |
| NSP06 NSP07 NSP08 NSP09 NSP10 | 100 200 200 100 200 | 1000 1000 1000 1000 1000 | 310 310 350 515 515 | 240 240 253 445 445 | NSP6 NSP7 NSP8 NSP9 NSP10 |
| NSP11 NSP12 | 200 200 | 1500 2000 | 500 515 | 420 445 | NSP11 NSP12 |
| HSK01 HSK02 | 100 100 | 200 250 | 150 150 | 70 70 | HSK1 HSK2 |
