Sakaguchi Electric Heaters CO.
Sakaguchi Fluoropolymer Wire
Manufacturer: Sakaguchi Electric Heaters CO., LTD.
Features
Specifications
| Conductor configuration | Insulator thickness (mm) | Standard Finish Outer Diameter (Approx.) (mm) | Product Code | |||
|---|---|---|---|---|---|---|
| Cross-sectional area (mm2)) | Number of wires/wire diameter (mm) | Outer Diameter (mm) | 100m Roll | Sale | ||
| 0.5 | 19/0.18 | 0.9 | 0.25 | 1.4 | TEF005 | TEF005C |
| 0.75 | 30/0.18 | 1.15 | 0.3 | 1.75 | TEF075 | TEF075C |
| 1.25 | 50/0.18 | 1.5 | 0.3 | 2.1 | TEF125 | TEF125C |
| 2.0 | 37/0.26 | 1.8 | 0.3 | 2.4 | TEF020 | TEF020C |
| 3.5 | 45/0.32 | 2.6 | 0.3 | 3.2 | TEF035 | TEF035C |
| 5.5 | 35/0.45 | 3.1 | 0.5 | 4.1 | *TEFX (made-to-order) | |
| 8.0 | 50/0.45 | 3.7 | 0.6 | 4.9 | ||
| 14.0 | 88/0.45 | 4.9 | 0.7 | 6.3 | ||
