Sakaguchi Electric Heaters CO.
Sakaguchi MPA Series liquid-expandable thermostat
Manufacturer: Sakaguchi Electric Heaters CO., LTD.
Model: MPA Series
Specifications
| Item | Specification |
|---|---|
| Series | MPA Series |
| Control Type | Mechanical interval timer (ON/OFF control) |
| Switch Type | SP–ST (Single Pole Single Throw), snap-action |
| Time Control Method | Dial setting (internal mechanical timer) |
| Time Adjustment Range | Min. 7–14% offset per rotation |
| Maximum Adjustment | Up to 100% (continuous adjustment) |
| Rated Voltage | 100 VAC / 200 VAC |
| Rated Current | 15 A |
| Dial Type | Knurled dial (with OFF position) |
| Terminals | AMP terminals |
| Manufacturer | Sakaguchi Electric Heaters |
| Model | Rated Voltage | Rated Current | Switch Type | Control Dial |
|---|---|---|---|---|
| MPA100P | 100 VAC | 15 A | SP–ST | Included |
| MPA200P | 200 VAC | 15 A | SP–ST | Included |
