Input Types: RTD: Pt100, JPt100
Output Types: 0–10mV, 0–100mV, -10–10mV, -100–100mV, 1–5V, 4–20mA, 0–5V, 0–10V
Accuracy: ±0.15% FS
Current: 1mA
Input Lead Resistance: ≤200Ω mỗi dây
Response Time: ≤170ms
Output Load:
1V span: ≤ 2mA
10mV span: ≥ 10kΩ
100mV span: ≥ 100kΩ
First output (current): ≤ 750Ω
Both outputs (current): First ≤ 550Ω, Second ≤ 350Ω
Power Supply: 100–240V AC hoặc 24V DC
Power Consumption:
100–240V AC: ≤ 7VA
24V DC: ≤ 2W
Operating Conditions:
Temp: -5 đến 55°C
Humidity: ≤ 90% RH (không ngưng tụ)
Dimensions: H86×W29×D125 mm
Weight: Main unit: 120g
Terminal block: 80g
