Shimaden SRP30 Series Digital Dontroller

Manufacturer: SHIMADEN CO., LTD.
Model: SRP30 Series

Features

A single unit handles everything from general-purpose use to advanced process control, offering a wide range of functions, high accuracy (0.1% FS), and high resolution (0.0001). It features the fastest sampling cycle of 50 ms, with selectable options of 50, 100, 200, and 500 ms. Multi-SV value settings allow up to 9 SV values, while the multi-PID function (No. 1-9) enables programming of up to 9 patterns and 180 steps.

Specifications

Category	Details
Input Types
Thermocouple	15 types
Resistance Thermometer	2 types
Voltage (mV)	3 types
Voltage Input (V)	4 types
Current Input	Used by attaching a separately sold shunt resistor to the voltage input
Display Accuracy	±0.1% FS + 1 digit
Reference Junction Compensation Accuracy	±1°C (18 to 28°C)
Ambient Temperature	-10 to 55°C
Display Update Cycle	Select from 0.05 seconds, 0.1 seconds, 0.2 seconds, or 0.5 seconds
Adjustment	Expert PID with auto-tuning function
Output Types
Contact	1a 240V AC 2.5A (resistive load)
Current	4-20mA DC Load resistance: 600Ω or less
SSR Drive Voltage	12V ±1.5V DC 20mA or less
Voltage	0 to 10V DC Load current: 2mA or less
Optional Features
Control Output 2	Contact, Current, SSR Drive Voltage, Voltage
Heater Break	2 points, 30A, 50A CT sold separately
Analog Output	1 point: 0 to 10mV, 4 to 20mA, 0 to 10V
External Control Input/Output	5 additional inputs, 6 additional outputs (max.)
Communication Function	RS-485, RS-232
General Specifications
Power Supply	100 to 240V AC ±10% (50/60Hz)
Power Consumption (SRP33)	Max. 18VA
Power Consumption (SRP34)	Max. 15VA
Storage Temperature	-20 to 65°C
Dimensions	SRP33: H96 x W96 x D111mm (inside panel depth 100mm) SRP34: H96 x W48 x D111mm (inside panel depth 100mm)
Weight	SRP33: Approx. 410g SRP34: Approx. 280g
