• Seal chamber
  Seal chamber dimensions fully conform to API682 and API610 standards, with installation of our own standard-dimension dual seals also supported.
• Easy maintenance
  Overhaul can be performed without removal of main pipelines or drive assembly.
• High reliability
  Balance drum reduces thrust force to an optimum level. Diffuser guide vane provides balance for internal radial force.
  Additionally, full-circular construction of the bearing housing and high-precision dynamic balance ensure stable operation and long bearing life.
• Self-venting
  Both the discharge and suction nozzles are located on top, which enables self-venting and achieves a smoother start-up.

Specifications

• Maximum flow rate:1100m³/h
• Maximum discharge pressure:2500# Flange rating

• Maximum operating temperature:400℃
• Maximum speed:6000rpm
