• Seal chamber
  Seal chamber dimensions fully conform to API682 and API610 standards, with installation of our own standard-dimension dual seals also supported.
• Easy maintenance
  Overhaul can be performed without removal of main pipelines or drive assembly.
• High reliability
  The double volute casing design and double suction impeller, as well as the impeller rear alignment arrangement, reduce the radial force and thrust force balance of the pump, achieving stable operation and prolonging bearing life.

Specifications

• Maximum flow rate:2000m³/h
• Maximum diff. head:650m
• Maximum operating temperature:200℃
