Thing Tech TRE/ MRES Series End Track (Aluminum)

Manufacturer: THING TECH CO., LTD.
Model: TRE/ MRES Series

Rail System

Lightweight Rails You Can Use with Confidence

Knight’s rail system offers both aluminum rails and steel rails.
Aluminum rails are lightweight and extruded, making operating loads lighter — this is their key advantage.
Steel rails feature high load capacity despite their compact size.
Both systems include excellent fall-prevention measures, providing safe and reliable lightweight rails for users.

Applications

Transporting parts and products
Rails for mounting auxiliary equipment
Care-support rails
Guides for lifting devices


Rail System Installation Examples	Rail System Installation Examples	Rail System Installation Examples	Door-off Device

Aluminum Rails

A rail system is a surface-transport system composed of X- and Y-axis movement.
In particular, aluminum rails are lightweight, offer excellent travel performance, do not corrode, and—thanks to precision extrusion—provide highly accurate operability.
Installation is also simple: all components are constructed using dedicated brackets, eliminating the need to drill holes, cut, or weld the rails.

By combining the rail system with an air balancer, 3-dimensional transport of heavy objects becomes possible.

We offer both aluminum rails and steel rails to suit various environments and purposes.

Main Applications

For transporting parts and products
As rails for auxiliary mounted equipment
As care-support rails
As guides for lifting devices

Both aluminum and steel rails are equipped with fall-prevention pins, ensuring safety even if a trolley were to fail.
The hangers and end trucks use through-rail bolts (patented), which significantly reduce the risk of falling.
Trolleys feature an anti-kick-up mechanism (prevents lifting), eliminating rattling during transport.
Trolleys are also equipped with side rollers, preventing horizontal sway.
Telescopes and rails can be used vertically as well.
The tool rail is ergonomically designed to minimize the force required to move loads horizontally.
Smooth operation allows heavy objects to be transported with much less effort.

End Track (Aluminum)

End tracks are used when installing runway rails and bridge rails at the same height.
They are mounted between runway rails and are suitable for applications where installation height is limited.

Note: The center section of Knight’s end track (trolley) contains a fall-prevention pin rated for a load capacity of 900 kg.

Drawing Data

Section	Part Number	Product Name
2-inch End Track	TRE-2025	T-End Track
2-inch End Track	TRE-2026	Heavy-Duty End Track
2-inch End Track	TRE-2062	2-inch → 4-inch End Track (Dual Bridge)
4-inch End Track	MRES4025	4-inch Single Trolley End Track (Single Bridge)
4-inch End Track	MRES4028	4-inch Trackless End Track (Bridge Span up to 3.04 m)
4-inch End Track	MRES4072	4-inch Single Trolley End Track (Dual Bridge)
4-inch End Track	MRES4073	4-inch Dual Trolley End Track
4-inch End Track	MRES4226	4-inch Dual Trolley End Track (No Swing)
4-inch End Track	MRES4295	4-inch Trackless End Track (Bridge Span over 3.04 m)
4-inch End Track	MRES4310	4-inch Low-Profile Single Trolley End Track (Single Bridge)
4-inch End Track	MRES4311	4-inch Low-Profile Dual Trolley End Track (Dual Bridge)
4-inch End Track	MRES4330	4-inch Single Trolley End Track (Steel Bridge)
4-inch End Track	MRES4395	4-inch Low-Profile Trolley End Track (Steel Bridge)
4-inch End Track	MRES4396	4-inch Low-Profile Trolley End Track (Steel Bridge)
4-inch End Track	MRES4398	4-inch Low-Profile Trolley End Track (Steel Bridge)
4-inch End Track	MRES4403	4-inch Single Trolley Curved Rail End Track (Single Bridge)
4-inch End Track	MRES4432	4-inch Height-Adjustable Single Trolley End Track (Single Bridge)
8-inch End Track	MRES7717	7500 Series Single Trolley End Track (Dual Aluminum Bridge)
8-inch End Track	MRES7718	7500 Series Dual Trolley End Track (Dual Aluminum Bridge)
8-inch End Track	MRES7728	7500 Series Single Trolley End Track (Single Aluminum Bridge)
8-inch End Track	MRES7730	7500 Series Single Trolley End Track (Single Steel Bridge)
8-inch End Track	MRES7735	7500 Series Dual Trolley End Track (No Swing)
8-inch End Track	MRES7756	7500 Series Dual Trolley End Track (Dual Steel Bridge)
8-inch End Track	MRES7775	7500 Series Trackless End Track (Bridge Span over 3.04 m)
8-inch End Track	MRES7777	7500 Series Height-Adjustable Single Trolley End Track
8-inch End Track	MRES7900	7500 Series Single Trolley End Track (Dual Steel Bridge)
8-inch End Track	MRES7903	7500 Series Low-Profile Trolley End Track (Dual Bridge)
8-inch End Track	MRES7904	7500 Series Low-Profile Trolley End Track (Single Bridge)
