TMK Tamaki
TMK Tamaki Iron Works TSN-200 Single Function Machine With NC
Manufacturer: Tamaki Iron Works Co., Ltd.
Model: TSN-200
Feature
- Single-purpose machine with NC device
- The photo shows the model with autoloader / unloader.
Specifications
| Standard chuck size | 8 inches |
| Bed maximum swing | ø450mm |
| Maximum machining diameter | ø200mm |
| Main shaft bearing inner diameter | ø90mm |
| Rotation speed (MAX) | 2000rpm |
| Slide Stroke | Z=230st, X=100st |
| Main shaft motor | 3.7/5.5kw |
| Hydraulic motor | 1.5kw x 4P |
| Hydraulic pump | Variable discharge double pump |
| Machine weight | 1700kg |
