Towa Seiden Kogyo Co.
Towa Seiden Emergency Pull Cord Switch
Manufacturer: Towa Seiden Kogyo Co., Ltd.
Features
The emergency pull cord switch offers a robust design with a large pull cord tension, ensuring reliability in demanding environments. Its two-way operation allows for convenient control from both directions, providing ease of use no matter the situation. Equipped with two built-in contacts, the switch offers distinct functionality—one for stopping and one for triggering an alarm, enhancing safety and efficiency.
Furthermore, this switch is dustproof and waterproof, making it the perfect choice for outdoor use and harsh conditions. Its durability and versatility ensure that it performs optimally in various environments, providing long-term value and safety for industrial and commercial applications.
Specifications
| Protective Structure | Dust-proof IP67 |
| Number of Contacts | 2 contacts (1c contact each) |
| Contact Capacity | 250V AC 10A (inductive load) |
| Tow Rope Required Force | 49±10N (5±1kgf) |
| Wire Outlet | For cable diameters of 8 to 12 mm |
| Ambient Temperature | −20 degrees to +60 degrees |
| Paint Color | Pantone: orange021C (AkzoNobel: EF001T) |
