Toyo Belt Disc Sander BD460A

Manufacturer: Toyo Associates, Ltd.
Features
This sanding machine is an essential tool for finishing work and provides reliable performance for both woodworking and metal polishing tasks. It combines a belt sander and a disc sander, which allows users to handle different finishing processes efficiently. The belt sander features a 100 mm wide belt that provides a large working surface and supports stable material processing. In addition, the sanding disc measures 150 mm in diameter, which allows effective surface polishing and finishing.
Furthermore, the machine supports both horizontal and vertical belt sanding positions. While the standard setup uses the horizontal position, users can also polish materials with the belt placed vertically, which increases flexibility during operation. The machine also includes a rocker-type power switch that allows the key to be removed. As a result, the removable key improves safety because the machine cannot be operated when the key is removed, especially when the operator is away from the equipment.
Specifications
| Rotational speed | 50Hz | disk | 2,800min-1 [revolutions/minute] |
| belt | 448m/min-1 | ||
| 60Hz | disk | 3,400min-1 [revolutions/minute] | |
| belt | 540m/min-1 | ||
| Belt Dimensions | Width 100 x circumference 915mm | ||
| Disc Dimensions | φ152mm | ||
| Work table | Dimensions: Width 225 x Depth 150 mm | ||
| Angle 0~45° | |||
| motor | 100V 50/60Hz | ||
| Rated power consumption | 450W | ||
| own weight | 22.5kg | ||
| Body dimensions | W500×D450×H300mm | ||
