Manufacturer: Toyo Associates, Ltd.

Features

This gauge is specifically designed to align the thread cutting tool vertically during metric screw machining, and it ensures precise positioning before the cutting process begins. Because accurate alignment directly determines thread accuracy and surface quality, this gauge allows you to set the tool at the correct angle relative to the workpiece with confidence. As you reference the gauge during setup, you reduce alignment errors and improve the consistency of the thread profile. In addition, it is highly useful for adjusting the center, thereby helping you achieve proper tool height and concentricity. Consequently, you enhance cutting stability, minimize tool wear, and prevent dimensional inaccuracies. Therefore, this gauge becomes an essential accessory for precise metric threading and efficient, professional-grade lathe operations.

Specifications
