Venn Co.
Venn KT-1PN type strainer
Manufacturer: Venn Co., Ltd.
Model: KT-1PN
Features
- This is a straight-type strainer with a completely new concept.
- It solves common problems of conventional strainers, such as construction difficulty, maintenance issues, and pressure loss.
- In addition, the KT-1PN type features an epoxy resin powder coating for water supply applications.
- Moreover, the KT-1CN type uses a durable nylon coating.
Specifications
| Product code | KT1PN-G |
|---|---|
| Valve type | Straight type |
| type | Epoxy resin powder coating |
| Nominal diameter | 50-200 (2-8) |
| Applicable fluid | Water / hot water |
| Fluid temperature | 5-60 ℃ |
| Applicable pressure | 1.0MPa or less |
| End connection | JIS 10K FF flange |
| Mesh | 60 mesh 20, 40, 80, 100 mesh |
| Tolerant differential pressure | 0.1MPa or less |
| Painting | Body / lid: Epoxy resin powder coating on both inner and outer surfaces 0 3 mm or more (gray color) |
| Material body | FC |
| Material net | SUS |
