Venn Co.
Venn KT-8CN Strainer
Manufacturer: Venn Co., Ltd.
Model: KT-8CN
Features
- The uniquely designed stopper allows easy disassembly and cleaning.
- In addition, it complies with waterworks performance standards and supports pressures up to 2.0 MPa.
Specifications
| Product Symbol | KT8CN-M |
|---|---|
| Types of valves | Straight |
| Types | Nylon Coating |
| Nominal diameter | 40～100（1 1/2～4） |
| Applicable fluids | Water and hot water |
| Fluid temperature | 5～60℃ |
| Application pressure | 2.0MPa or less |
| End connection | JIS 20K RF Flange |
| Website | 60 Mesh 20, 40, 80, 100 Mesh |
| Allowable differential pressure | Less than 0.1MPa |
| Painting | Body/lid: Nylon 11 coating on both internal and external surfaces 0 3mm or more (white) |
| Material: Body | FCD |
| Material: Net | SUS |
