Venn PF-12 Solenoid Valve (for Steam, Liquid, Air)
Manufacturer: Venn Co., Ltd.
Model: PF-12
Features
- It is compatible with steam, water, air, and oil.
- In addition, it can use over a wide pressure range from 0 to 1.0 MPa.
- Moreover, the series includes both energized-open and energized-closed types.
Specifications
| Product Symbol | PF12-W |
|---|---|
| Types | piston |
| Activate | Power on |
| Nominal diameter | 65・80（2 1/2・3） |
| Applicable fluids | Steam, water, air, oil (about kerosene, light oil) |
| Fluid temperature | 5~180°C (100°C or less for hot water) |
| Fluid viscosity | Below 20cSt |
| Application pressure | 0~1.0MPa (Nominal Diameter 65), 0.05~1.0MPa (Nominal Diameter 80) |
| Minimum differential pressure before and after the valve | 0MPa (0.05MPa for nominal diameter 80) |
| Allowable leakage | Steam, water, oil: None (pressure gauge visual), Air: 50mL/min (standard condition) or less (0.05~1.0MPa) |
| Rated voltage | AC100/200V 50/60Hz AC110/220V 60Hz Shared |
| Insulation type | H type |
| Ambient temperature | 5～60℃ |
| Protective structure | Dustproof, splash-proof, and indoor use (If used outdoors, please use the TB-03 terminal box together.) |
| End connection | JIS 10K FF Flange |
| Mounting Position | Upright mounting with coils up on horizontal piping |
| Material: Body | CAC406, nominal diameter 80 is FC |
| Material: Valve body | SUS, PTFE discs |
