Venn PS-17 Solenoid Valve (for Steam)
Manufacturer: Venn Co., Ltd.
Model: PS-17
Features
- It designs for high-pressure fluid use.
- In addition, it makes of stainless steel, making it suitable for high-pressure water and steam.
Specifications
| Product Symbol | PS17-V |
|---|---|
| Types | piston |
| Activate | Power on |
| Nominal diameter | 10～50（3/8～2） |
| Applicable fluids | Steam |
| Fluid temperature | 5～200℃ |
| Fluid viscosity | ── |
| Application pressure | 0.05～1.6MPa |
| Minimum differential pressure before and after the valve | 0.05MPa |
| Allowable leakage | Less than 3 g/min |
| Rated voltage | AC100/200V 50/60Hz AC110/220V 60Hz Shared |
| Insulation type | H type |
| Ambient temperature | 5～40℃ |
| Protective structure | Dustproof, splash-proof, and indoor use (If used outdoors, please use the TB-03 terminal box together.) |
| End connection | JIS Rc Screw |
| Mounting Position | Upright mounting with coils up on horizontal piping |
| Material: Body | SCS |
| Material: Valve body | SUS, PTFE discs |
