Venn PS-22C type solenoid valve (for steam, liquid, air)
Manufacturer: Venn Co., Ltd.
Model: PS-22C
Features
- It has passed an operating durability test of one million cycles (Note).
- This applies to nominal diameters of 25 or less, based on in-house testing.
- In addition, it can use with steam, water, air, and oil.
- Moreover, it operates across a wide pressure range from 0 to 1.0 MPa.
- Vertical and horizontal installation supports.
- Finally, for nominal diameters of 25 or less, the coil exterior makes of heat-resistant thermosetting resin.
Specifications
| Product code | PS22C-W |
|---|---|
| type | Piston type |
| Actuation | Energized closed |
| Nominal diameter | 10-50 (3 / 8-2) |
| Applicable fluid | Steam / water / air / oil (kerosene / light oil) |
| Fluid temperature | 5 to 180 ° C (100 ° C or less for hot water) |
| Fluid viscosity | 20cSt or less |
| Applicable pressure | 0-1.0MPa |
| Minimum differential pressure before and after the valve | 0MPa (0.03MPa when the coil is horizontal) |
| Allowable leakage amount | Steam / water / oil: None (visual pressure gauge), air: 50 mL / min (standard condition) or less (at 0.05 to 1.0 MPa) |
| Rated voltage | AC100 / 200V 50 / 60Hz AC110 / 220V 60Hz shared |
| Insulation type | H species |
| Ambient temperature | 5-60 ℃ |
| Protective structure | Dustproof / splashproof / indoor use (When using outdoors, use the TB-03 type terminal box together. |
| End connection | JIS Rc screw |
| Mounting posture | Horizontal / vertical (excluding the coil downward with respect to the mounting pipe) |
| Material body | CAC408 |
| Material Valve body | C3604, with PTFE disc |
