Venn WS-12 type solenoid valve (for liquids and gases)
Manufacturer: Venn Co., Ltd.
Model: WS-12
Features
- It is suitable for both liquids and gases.
- In addition, it can use across a wide pressure range from 0 to 1.0 MPa.
- Moreover, it equips with a water hammer mitigation mechanism.
- Both energized-open and energized-closed types are available in the series.
Specifications
| Product code | WS12-F |
|---|---|
| type | Diaphragm type |
| Actuation | Energized open |
| Nominal diameter | 65 (2 1/2) |
| Applicable fluid | Water / air・ Inert gas・ Oil (kerosene / light oil) |
| Fluid temperature | 5-60 ℃ |
| Fluid viscosity | 20cSt or less |
| Applicable pressure | 0-1.0MPa |
| Minimum differential pressure before and after the valve | 0MPa |
| Allowable leakage amount | None (visual pressure gauge, when gas is 0.02 to 1.0 MPa) |
| Rated voltage | AC100 / 200V 50 / 60Hz AC110 / 220V 60Hz shared |
| Insulation type | Type B |
| Ambient temperature | 5-60 ℃ |
| Protective structure | Dust-proof, drip-proof, indoor use (when using outdoors, use the TB-03 type terminal box together. ) |
| End connection | JIS Rc screw |
| Mounting posture | Upright mounting with coil up on horizontal piping |
| Rated current | AC100V: 0.60A, AC200V: 0.30A |
| Starting current | AC100V: 2.50A, AC200V: 1.25A |
| Material body | CAC406 |
| Material diaphragm | NBR |
