Venn Co.
Venn WS-22N type constant water level valve (FV valve) related products
Manufacturer: Venn Co., Ltd.
Model: WS-22N
Specifications
| Product code | WS22N-F |
|---|---|
| Valve type | Solenoid valve for pilot |
| type | Body made of bronze |
| Nominal diameter | 20/25 (3/4/1) |
| Applicable pressure | 0 to 1.0 MPa (0.03 to 1.0 MPa when the coil is horizontal) |
| Rated voltage | AC100V 50 / 60Hz AC200V 50 / 60Hz shared |
| Rated current | AC100V: 0.21A AC200V: 0.10A |
| Starting current | AC100V: 0.7A AC200V: 0.35A |
| Protective structure | Dustproof, splashproof, indoor use |
| Cv value | Nominal diameter 20: 7, Nominal diameter 25:10 |
| Material body | CAC408 |
| Material parts | SUS / NBR |
