Venn WS-25CN Constant Water Level Valve (FV Valve) Related Products
Manufacturer: Venn Co., Ltd.
Model: WS-25CN
Specifications
| Product Symbol | WS25CN-D |
|---|---|
| Types of valves | Pilot solenoid valve |
| Types | bodystainless steel |
| Nominal diameter | 20・25（3/4・1） |
| Application pressure | 0~1.0MPa (0.03~1.0MPa if the coil is horizontal) |
| Rated voltage | AC100V 50/60Hz AC200V 50/60Hz Shared |
| Rated current | AC100V：0.35A AC200V：0.18A |
| Starting current | AC100V：1.30A AC200V：0.65A |
| Protective structure | Dustproof, splash-proof/indoor |
| Cv value | Nominal diameter 20:7, nominal diameter 25:10 |
| Material: Body | SCS |
| Material Key parts | SUS/NBR |
