Wadeco Ranging Microwave Slab Tracking Sensor Microtracker MWS-MT-1

Manufacturer: Wadeco Corporation
Model: MWS-MT-1
Features
- No license requiredNo
radio station license required, saving the cost and hassle of applying for a license. - OK
in adverse environments Microwave is not affected by high temperatures, water vapor, flames, water flowing over the slab, shower.
Use the option if you need heat protection. - High reliability Detects the presence or absence of slabs with or without reflection from the
reflector. Since it is detected digitally, the presence or absence of slabs is reliably detected. - Fast response
50 msec. update time. - There is no misalignment of the beam axis The transmitting and receiving beams are conical in shape, making it easy to adjust the beam axis and there is no malfunction due to axis misalignment.
- You can install a microtracker in close proximity that does not
interfere with the set. - Outdoor
- Affordable price
Specification
format | Body: MWS-MT-1 Reflector: CR-200T (not required when mounted on top) |
---|---|
power | AC90~240V、50/60Hz |
Power consumption | 10VA |
Measuring distance | 10m (distance from the antenna to the reflector) |
Frequency and aerial power | 24GHz band, 10mW or less |
