Wadeco Ranging Millimeter-Wave Slab Tracking Sensor Millimeter Tracker MWS-MT-2

Manufacturer: Wadeco Corporation
Model: MWS-MT-2
Features
- No license requiredNo
radio station license required, saving the cost and hassle of applying for a license. - OK
in adverse environments mmWave is not affected by high temperatures, water vapor, flames, water flowing over the slabs, showers.
Use the option if you need heat protection. - High reliability detects the presence or absence of slabs with or without reflections from the
rolls. Since it is detected digitally, the presence or absence of slabs is reliably detected. - Fast response
approx. 5msec. Realize the update time. - By using a millimeter-wave beam with high precision
and sharp directionality, the presence or absence of slabs is accurately detected. - There is no misalignment of the beam axis The transmitting and receiving beams are conical in shape, making it easy to adjust the beam axis and there is no malfunction due to axis misalignment.
- Multiple millimeter trackers that do not
interfere with the set can be installed close together.
Specification
format | Body: MWS-MT-2 |
---|---|
power | DC24V |
Power consumption | 10VA |
Measuring distance | 1.5~6.0m (distance from antenna to reflector) |
Frequency and aerial power | 79GHz band, 10mW or less |
