Datalink Corporation
DataLink MMOPT-R Series Fiber Optic USB Extender

Manufacturer: DataLink
Model: MMOPT-R
Features
- Uses a commercially available single-core SC multimode optical cable.
- Maximum extension distance: 2 km.
- Optical fiber prevents equipment malfunction or damage from induced lightning and external noise.
- Power supply is optional (customer-provided).
- Input voltage range: DC6V to DC24V
- A dedicated AC adapter is available separately.
- You can mount the device on a DIN rail using an optional bracket.
Use the dip switches on the bottom to configure the communication settings.
Specifications
Model MMOPT-R Supported Communication Methods Asynchronous Serial Connector Dsub9Pin Male DTE Optical Connector 1-core SC cable compatible connector Maximum Communication Speed Maximum 115.2Kbps External Dimensions W93 × H27 × D104mm ±1 (excluding connectors and other protrusions) Weight Approx. 300g per unit
