DEICY
Deicy NG360 Full-Angle Inclination Sensor
Manufacturer: DEICY Co., Ltd.
Model: NG360
Features
Overall, the device combines high precision, flexibility, and ease of use. It delivers stable and repeatable measurement performance thanks to its advanced gyro sensor, while also supporting bidirectional rotation measurement with high resolution and no hysteresis. In addition, users can independently configure the measurement range and low-pass filter for each channel, which enhances adaptability. Moreover, temperature compensation and excellent linearity ensure reliable results under varying conditions. Finally, the lightweight and compact design, along with simple assembly that requires no cable connections, greatly improves portability and operational efficiency.
Specifications
| Model | Measurement Range | Resolution | Non-Linearity | Cross Sensitivity | Response Time | Power Supply | Current Consumption | Case Protection Grade | Operating Temperature Range | Ambient Temperature Range | Weight (without cable) | Housing Material | Connection Cable |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| N360 | 360° | 0.01° | ±0.25° | ±0.1° (at 45° tilt) | Approx. 0.3 seconds | 9~15V DC | Approx. 40mA (Ub=5V) | IP65 | −40°C to +85°C | −45°C to +90°C | Approx. 110g | Reinforced fiberglass housing | Diameter 4.6mm, length 1.0m shielded cable |
