Deicy NG*i/NG*U Series Liquid-Filled Capacitive Signal Conditioner Built-In Inclination Angle Sensor
Manufacturer: DEICY Co., Ltd.
Model: NG*i / NG*U Series
Features
- Excellent long-term stability and low power consumption.
- High precision linearity with no hysteresis.
- IP65 dustproof and waterproof housing.
- EMC-compliant, usable even in strong electromagnetic fields.
Specifications
| Model | Measuring Range | Sensitivity | Resolution | Non-linearity | Cross Sensitivity | Response Time | Temperature Drift | Zero Drift | Voltage Range | Output Signal (0°) | Protection Level | Operating Temperature Range | Storage Temperature Range | Shock Resistance | Weight (without cable) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NG2i | ±10° | 0.8mA/° | <0.001° | 0.02° | <0.5% (45° tilt) | Approx. 0.3 sec | Approx. -0.01%/°C | Approx. ±10°/°C | Ubz=10~30V | 12mA | IP65 | -40°C ~ +85°C | -45°C ~ +90°C | 100G | Approx. 110g |
| NG3i | ±30° | 0.266mA/° | <0.003° | 0.06° | <0.5% (45° tilt) | Approx. 0.3 sec (Option: 1s, 2s, 3s) | Approx. -0.01%/°C | Approx. ±10°/°C | Ubz=10~30V | 12mA | IP65 | -40°C ~ +85°C | -45°C ~ +90°C | 100G | Approx. 110g |
| NG4i | ±80° | 0.1mA/° | <0.01° | 0.16° | <0.5% (45° tilt) | Approx. 0.3 sec | Approx. -0.01%/°C | Approx. ±10°/°C | Ubz=10~30V | 12mA | IP65 | -40°C ~ +85°C | -45°C ~ +90°C | 100G | Approx. 110g |
