Deicy OMS4100 Series Laser Displacement Sensor
Manufacturer: DEICY Co., Ltd.
Model: OMS4100 Series
Features
- Compact and lightweight (approximately 95g) despite having a built-in amplifier
- Operates on a 10 to 30V power supply
- High-speed measurement rate of 1kHz
Specifications
| Item | OMS 4108 | OMS 4120 | OMS 4122 | OMS 4140 |
|---|---|---|---|---|
| Measuring Range (mm) | 80 | 200 | 200 | 400 |
| Stand off (mm) | 70 | 150 | 300 | 300 |
| Resolution (mm) (with standard filter 200 Hz) | 0.040 | 0.100 | 0.100 | 0.200 |
| Linearity (FSO) | ≤ ±0.3% Full Scale Output | Same as left | ||
| Repeatability (FSO) | ≤ ±0.1% Full Scale Output | Same as left | ||
| Frequency Bandwidth | 1 kHz max (can be specified at order time based on application) | |||
| Filter | Digital average (can be specified at order time based on application) | |||
| Light Source | Laser Diode | |||
| Spot Diameter | 0.05 ~ 5 mm (can be specified at order time based on application) | |||
| Wavelength | 660 ~ 780 nm (can be specified at order time based on application) | |||
| Laser Class | 2/3R/3B (can be specified at order time based on application) | |||
| Detection Method | CMOS Linear Image Sensor | |||
| Power Supply | 10 ~ 30 V DC / 100 mA | |||
| Output | 0 ~ 5 V / 0 ~ 20 mA / CAN (can be specified at order time based on application) | |||
| Operating Temperature | -20°C to +50°C (no condensation) | |||
| Shape | 65 × 50 × 20 mm | |||
| Weight | Approx. 95 g | |||
| Protection Rating | IP65 | |||
