Manufacturer: Hirosugi Instruments Co., Ltd.
Model: ASU-2000

Specification

Material

Free-cutting stainless steel (SUS303)

process

Degreasing

Exterior drawings

Thread diameter (pitch)	L	Part Number	ℓ1
M2 (0.4)	3	ASU-2003	Fully threaded
	3.5	ASU-2003.5
	4	ASU-2004
	4.5	ASU-2004.5
	5	ASU-2005
	5.5	ASU-2005.5
	6	ASU-2006
	6.5	ASU-2006.5
	7	ASU-2007
	7.5	ASU-2007.5
	8	ASU-2008
	8.5	ASU-2008.5
	9	ASU-2009
	9.5	ASU-2009.5
	10	ASU-2010
	10.5	ASU-2010.5
	11	ASU-2011	5
	11.5	ASU-2011.5	5
	12	ASU-2012	5
	12.5	ASU-2012.5	5
	13	ASU-2013	5
	13.5	ASU-2013.5	5
	14	ASU-2014	5
	14.5	ASU-2014.5	5
	15	ASU-2015	5
	15.5	ASU-2015.5	5
	16	ASU-2016	5
	16.5	ASU-2016.5	5
	17	ASU-2017	5
	17.5	ASU-2017.5	5
	18	ASU-2018	5
	18.5	ASU-2018.5	5
	19	ASU-2019	5
	19.5	ASU-2019.5	5
	20	ASU-2020	5
	20.5	ASU-2020.5	5
	twenty one	ASU-2021	5
	21.5	ASU-2021.5	5
	twenty two	ASU-2022	5
	22.5	ASU-2022.5	5
	twenty three	ASU-2023	5
	23.5	ASU-2023.5	5
	twenty four	ASU-2024	5
	24.5	ASU-2024.5	5
	twenty five	ASU-2025	5
	25.5	ASU-2025.5	5
	26	ASU-2026	5
	26.5	ASU-2026.5	5
	27	ASU-2027	5
	27.5	ASU-2027.5	5
	28	ASU-2028	5
	28.5	ASU-2028.5	5
	29	ASU-2029	5
	29.5	ASU-2029.5	5
	30	ASU-2030	5
