Manufacturer: Hirosugi Instruments Co., Ltd.
Model: BSB-2600-3E

Specification

Material

Free-cutting brass (C3604BD)
Cadmium content less than 75 ppm

Process

Nickel plating (Ni)

Exterior drawings

Thread diameter, flat diameter (pitch)	L	Part Number	ℓ1
M2.6 3.5 (0.45)	4	BSB-2604-3E	2.5
	4.5	BSB-2604.5-3E	2.5
	5	BSB-2605-3E	3
	5.5	BSB-2605.5-3E	3.5
	6	BSB-2606-3E	4
	6.5	BSB-2606.5-3E	4.5
	7	BSB-2607-3E	5
	7.5	BSB-2607.5-3E	5
	8	BSB-2608-3E	5
	8.5	BSB-2608.5-3E	5
	9	BSB-2609-3E	5
	9.5	BSB-2609.5-3E	5
	10	BSB-2610-3E	5
	10.5	BSB-2610.5-3E	5
	11	BSB-2611-3E	5
	11.5	BSB-2611.5-3E	5
	12	BSB-2612-3E	5
	12.5	BSB-2612.5-3E	5
	13	BSB-2613-3E	5
	13.5	BSB-2613.5-3E	5
	14	BSB-2614-3E	5
	14.5	BSB-2614.5-3E	5
	15	BSB-2615-3E	5
	15.5	BSB-2615.5-3E	5
	16	BSB-2616-3E	5
	16.5	BSB-2616.5-3E	5
	17	BSB-2617-3E	5
	17.5	BSB-2617.5-3E	5
	18	BSB-2618-3E	5
	18.5	BSB-2618.5-3E	5
	19	BSB-2619-3E	5
	19.5	BSB-2619.5-3E	5
	20	BSB-2620-3E	5
	twenty one	BSB-2621-3E	5
	twenty two	BSB-2622-3E	5
	twenty three	BSB-2623-3E	5
	twenty four	BSB-2624-3E	5
	twenty five	BSB-2625-3E	5
	26	BSB-2626-3E	5
	27	BSB-2627-3E	5
	28	BSB-2628-3E	5
	29	BSB-2629-3E	5
	30	BSB-2630-3E	5
