Manufacturer: Hirosugi Instruments Co., Ltd.
Model: BSU-400-6

Specification

Material

Free-cutting stainless steel (SUS303)

process

Degreasing

Exterior drawings

Tolerance of L
: ±0.1 up to L=60
, ±0.2 from L=62

Thread diameter (pitch)	L	Part Number	ℓ1
M4 (0.7)	6	BSU-406-6	3.5
	6.5	BSU-406.5-6	3.5
	7	BSU-407-6	4.5
	7.5	BSU-407.5-6	4.5
	8	BSU-408-6	5.5
	8.5	BSU-408.5-6	5.5
	9	BSU-409-6	6
	9.5	BSU-409.5-6	6
	10	BSU-410-6	7
	11	BSU-411-6	8
	12	BSU-412-6	8
	12.5	BSU-412.5-6	8
	13	BSU-413-6	8
	14	BSU-414-6	8
	15	BSU-415-6	8
	16	BSU-416-6	8
	16.5	BSU-416.5-6	8
	17	BSU-417-6	8
	17.5	BSU-417.5-6	8
	18	BSU-418-6	8
	19	BSU-419-6	8
	20	BSU-420-6	8
	twenty one	BSU-421-6	8
	twenty two	BSU-422-6	8
	twenty three	BSU-423-6	8
	twenty four	BSU-424-6	8
	twenty five	BSU-425-6	8
	26	BSU-426-6	8
	27	BSU-427-6	8
	28	BSU-428-6	8
	29	BSU-429-6	8
	30	BSU-430-6	8
	31	BSU-431-6	8
	32	BSU-432-6	8
	33	BSU-433-6	8
	34	BSU-434-6	8
	35	BSU-435-6	8
	36	BSU-436-6	8
	37	BSU-437-6	8
	38	BSU-438-6	8
	39	BSU-439-6	8
	40	BSU-440-6	8
	41	BSU-441-6	8
	42	BSU-442-6	8
	43	BSU-443-6	8
	44	BSU-444-6	8
	45	BSU-445-6	8
	46	BSU-446-6	8
	47	BSU-447-6	8
	48	BSU-448-6	8
	49	BSU-449-6	8
	50	BSU-450-6	8
	51	BSU-451-6	8
	52	BSU-452-6	8
	53	BSU-453-6	8
	54	BSU-454-6	8
	55	BSU-455-6	8
	56	BSU-456-6	8
	57	BSU-457-6	8
	58	BSU-458-6	8
	59	BSU-459-6	8
	60	BSU-460-6	8
	62	BSU-462-6	8
	64	BSU-464-6	8
65	BSU-465-6	8
66	BSU-466-6	8
68	BSU-468-6	8
70	BSU-470-6	8
72	BSU-472-6	8
74	BSU-474-6	8
75	BSU-475-6	8
76	BSU-476-6	8
78	BSU-478-6	8
80	BSU-480-6	8
85	BSU-485-6	8
90	BSU-490-6	8
95	BSU-495-6	8
100	BSU-4100-6	8
