Sakaguchi Electric Heaters CO.
Sakaguchi SCH Type Silicone belt heater
Manufacturer: Sakaguchi Electric Heaters CO., LTD.
Model: SCH Type
Features
Specifications
| Material | Heat-resistant silicone rubber |
|---|---|
| Operating temperature (*) | -50℃～180℃ |
| Insulation resistance | More than 100 MΩ at 500 mega DC |
| Insulation Voltage | 150V or less AC1000V/1 minute 150V or more AC1500V/1 minute |
| Connection Tensile Strength | 30N(3.06kgf) |
| Product Code | Length (mm) | Voltage (V) | Capacity (W) | Capacity per 1m (W/m) |
|---|---|---|---|---|
| SCH13 | 1,000 | 100 | 30 | 30 |
| SCH16 | 2,000 | 100 | 60 | 30 |
| SCH19 | 3,000 | 100 | 90 | 30 |
| SCH23 | 1,000 | 200/100 | 30/7.5 | 30/7.5 |
| SCH26 | 2,000 | 200/100 | 60/15 | 30/7.5 |
| SCH29 | 3,000 | 200/100 | 90/22.5 | 30/7.5 |
