Input Types:
0–5V DC
0–10V DC
1–5V DC
4–20mA DC
Alarm Output:
2 relay contact outputs (C contacts)
Alarm Operation:
Upper and lower limit alarms
Lower limit dual-stage alarm
Upper limit dual-stage alarm
Alarm Setting Accuracy: ±0.5% FS
Deadband: 1.0% ± 0.3% FS
Input Resistance:
Voltage input: ≥1MΩ
Current input: 250Ω
Input Response Time: ≤150ms
Contact Capacity: 125V AC, 5A
General Specifications:
Power Supply:
100–240V ±10% AC, 50/60Hz
24V DC ±10%
Power Consumption:
100–240V AC: ≤ 6.5VA
24V DC: ≤ 2W
Operating Conditions:
Temperature: -5 to 55°C
Humidity: ≤ 90% RH (without condensation)
External Dimensions: H86×W29×D125 mm
Weight:
Approx. 120g (main unit)
Approx. 80g (socket terminal block)
