Input Types:
0–1V DC
0–10V DC
0–5V DC
1–5V DC
4–20mA DC
Output Types:
0–10mV DC
0–100mV DC
0–1V DC
0–10V DC
0–5V DC
1–5V DC
4–20mA DC
Conversion Accuracy: ±0.2% (at 25°C ±5°C)
Input Resistance: ≥1MΩ
Response Time: ≤85ms
Output Load:
1V span or higher: Load current ≤ 2mA
10mV span or higher: Load resistance ≥ 10kΩ
100mV span or higher: Load resistance ≥ 100kΩ
First output only (current): Load resistance ≤ 750Ω

Both first and second outputs (current):

First output: Load resistance ≤ 550Ω

Second output: Load resistance ≤ 350Ω
Power Supply:
100–240V ±10% AC, 50/60Hz
24V DC ±10%
Power Consumption:
100–240V AC: ≤ 6.5VA
24V DC: ≤ 2.1W
Operating Conditions:

Temperature: -5 to 55°C
Humidity: ≤ 90% RH (without condensation)
External Dimensions: H86×W29×D125 mm
Weight:
Approx. 120g (main unit)

Approx. 80g (socket terminal block)
