Input types: 0-1V DC, 0-10V DC, 1-5V DC, 4-20mA DC
Output types: 0-10mV DC, 0-100mV DC, 0-1V DC, 0-10V DC, 0-5V DC, 1-5V DC , 4-20mA DC
Ratio setting range: 0.1 to 4x
Bias value setting range: -100 to 100%
Conversion accuracy: ±0.2% FS
Calculation formula: Y=KX+B Y:
Output signal (%) X:
Input signal (%) K:
Ratio B: Bias (%)
Response time: 85ms or less
Power supply: 24VDC ±10% , 100-240V ±10%, AC 50/60Hz
Power consumption: Single output type: 6.0VA (AC), 1.7W (DC)
Dual output type: 6.5VA (AC), 2.1W (DC)
Operating environment: -10 to 60°C 90% RH or less (no condensation)
External dimensions: H86 x W29 x D125 mm
Weight: Main unit 120g or less, socket terminal block 80g or less
Output types: 0-10mV DC, 0-100mV DC, 0-1V DC, 0-10V DC, 0-5V DC, 1-5V DC , 4-20mA DC
Ratio setting range: 0.1 to 4x
Bias value setting range: -100 to 100%
Conversion accuracy: ±0.2% FS
Calculation formula: Y=KX+B Y:
Output signal (%) X:
Input signal (%) K:
Ratio B: Bias (%)
Response time: 85ms or less
Power supply: 24VDC ±10% , 100-240V ±10%, AC 50/60Hz
Power consumption: Single output type: 6.0VA (AC), 1.7W (DC)
Dual output type: 6.5VA (AC), 2.1W (DC)
Operating environment: -10 to 60°C 90% RH or less (no condensation)
External dimensions: H86 x W29 x D125 mm
Weight: Main unit 120g or less, socket terminal block 80g or less
