Manufacturer: SHOWA PRECISION INDUSTRIES CO., Ltd.
Model: NT30W -CTH20 A / NT40U(M) -CTH25 A / NT40U(M) -CTH32 A / NT50U(M) -CTH32 A / NT50U(M) -CTH42 A
Specifications
| Model | Hard Chuck | Straight Collet | Hook Spanner | N/W (kg) |
|---|
| NT30W-CTH20 A | NT30W – CTH20 | SC20-06,08,10,12,16 | HOOK SPANNER | 2.25 |
| NT40U(M)-CTH25 A | NT40U(M) – CTH25 | SC25-06,08,10,12,16,20 | FK65-70 | 3.8 |
| NT40U(M)-CTH32 A | NT40U(M) – CTH32 | SC32-06,08,10,12,16,20,25 | FK80-85 | 5.6 |
| NT50U(M)-CTH32 A | NT50U(M) – CTH32 | SC32-06,08,10,12,16,20,25 | FK80-85 | 7.1 |
| NT50U(M)-CTH42 A | NT50U(M) – CTH42 | SC42-06,08,10,12,16,20,25,32 | FK92-100 | 10.8 |
| Model | Hard Chuck | Straight Collet | Taper Collet | Taper Collet (J6) | Hook Spanner | N/W (kg) |
|---|
| NT40U(M)-CTH25 B | NT40U(M)-CTH25 | SC25-06,08,10,12,16,20 | 25-MT1, MT2 | 25-J6 | FK65-70 | 4.5 |
| NT40U(M)-CTH32 B | NT40U(M)-CTH32 | SC32-06,08,10,12,16,20,25 | 32-MT1, MT2, MT3 | 32-J6 | FK80-85 | 7.5 |
| NT50U(M)-CTH32 B | NT50U(M)-CTH32 | SC32-06,08,10,12,16,20,25 | 32-MT1, MT2, MT3 | 32-J6 | FK80-85 | 9.3 |
| NT50U(M)-CTH42 B | NT50U(M)-CTH42 | SC42-06,08,10,12,16,20,25,32 | 42-MT1, MT2, MT3, MT4 | 42-J6 | FK92-100 | 13.5 |
