| Model No. | Power | Rotation speed (min-1) | 3-blade propeller | Shaft(mm) | Approximate equipment mass (kg) | Maximum agitating capacity(m3) | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| Output (kW) | Number of poles (P) | 50Hz | 60Hz | Impeller diameter φD | Shaft diameter φd | Standard length L | Homogeneous / uniform heat agitation | Uniform / diluted agitation | ||
| NSBM4 / NSBP4-004 | 0.4 | 4 | 300 | 360 | 250 | 30 | 400 | 48 | 6 | 1.5 |
| NSBM4 / NSBP4-007 | 0.75 | 300 | 30 | 450 | 50 | 10 | 3 | |||
| NSBM4 / NSBP4-015 | 1.5 | 350 | 35 | 500 | 70 | 20 | 6 | |||
| NSBM4 / NSBP4-022 | 2.2 | 400 | 40 | 500 | 120 | 30 | 9 | |||
| NSBM4 / NSBP4-037 | 3.7 | 450 | 45 | 550 | 130 | 50 | 14 | |||
| NSBM4 / NSBP4-055 | 5.5 | 500 | 50 | 700 | 240 | 75 | 20 | |||
| NSBM4 / NSBP4-075 | 7.5 | 550 | 60 | 700 | 250 | 100 | 30 | |||
| NSBM4 / NSBP4-110 | 11 | 600 | 65 | 800 | 360 | 150 | 45 | |||
| NSBM4 / NSBP4-150 | 15 | 650 | 70 | 800 | 380 | 200 | 60 | |||
| NSBM4 / NSBP4-220 | 22 | 700 | 80 | 850 | 450 | 300 | 80 | |||
Various shaft sealing methods and materials are available for different applications and liquid properties.
