Tohkemy Beta B Chemical Pump

Manufacturer: Tohkemy Corporation
Model: Beta B

Features

Operation mode
Manual Operation: Offers precise control through dual adjustments—stroke speed (0 to 180 spm) and stroke length (0 to 100%).
Remote Operation: External contact inputs turn the pump on and off remotely.
Pulse Interlocking: Synchronizes pump strokes directly with incoming pulse signals.
Durable & Waterproof Structure
Conforms to IEC standard IP65 for reliable operation in wet environments. An optional outdoor cover provides extra weather protection.
Air Extract Valves
Manual Air Extract Valve: Turning the knob releases trapped air directly from the pump head.
Automatic Air Extract Valve: Automatically purges trapped air from the pump head during operation.
Note: Specific liquid-end designs restrict air valve installation. Please contact us for model compatibility.
High-Viscosity Compatibility (PVT4 Type)
Handles viscous chemicals up to 3,000 mPa·s.
Note: Viscous applications limit total discharge capacity. Please consult our team for exact specifications.

Specifications

Discharge rate：- 533 mL/min
The discharge pressure is rated at – 2.5 MPa
Discharge accuracy：±2% (Conditions recommended by the manufacturer)
Connection： Hose(3×6、4×6、4×9、5×8、6×9、6×11、8×13、9×12 etc.) Piping connection is also possible(15A flange)

Pump size	At maximum pressure			At normal pressure			Power consumption (W)	Connection Hose diameter (resin) mm	Tube Outer diameter (SST)	Reference mass kg
	At maximum pressure			At normal pressure						Resin	SST
	Discharge rate		Discharge pressure	Discharge rate		Discharge pressure
	L/H	ml/min	MPa	L/H	ml/min	MPa
BT4b 1000	0.74	12.3	1.0	0.82	13.7	0.5	7.6	4×9	6mm	2.5	3.0
BT4b 1601	1.1	18.3	1.6	1.4	23.3	0.8	10.0	4×9		2.9	3.6
BT4b 1602	2.2	36.7	1.6	2.5	41.7	0.8	12.2	4×9		2.9	3.6
BT4b 1604	3.6	60.0	1.6	4.3	71.7	0.8	16.5	4×9		3.1	3.9
BT4b 0708	7.1	118.3	0.7	8.4	140.0	0.35	16.5	6×11	8mm	3.1	3.9
BT4b 0413	12.3	205.0	0.4	14.2	236.7	0.2	16.5	6×11	8mm	3.1	3.9
BT4b 0220	19.0	316.7	0.2	20.9	348.3	0.1	16.5	8×13.5	12mm	3.3	4.4
BT5b 1008	6.8	113.3	1.0	8.3	138.3	0.5	20.3	6×11	8mm	4.5	5.3
BT5b 0713	11.0	183.3	0.7	13.1	218.3	0.35	21.2	6×11	8mm	4.5	5.3
BT5b 0420	17.1	285.0	0.4	19.1	318.3	0.2	21.2	8×13.5	12mm	4.7	5.8
BT5b 2504	2.9	48.3	2.5	5	83.3	1.0	21.2	No setting	6mm	–	5.3
BT5b 0232	32	533.3	0.2	36.2	603.3	0.1	24.9	8×13.5	12mm	5.1	6.6

Option
＜Relay output＞
Alarm relay: Outputs a non-voltage contact signal when an abnormality such as a defective pump body or a low liquid level in a chemical tank occurs.
Pacing relay: Outputs a voltage-free contact signal for each stroke, making it possible to use this signal for synchronized operation of another identical pump or for monitoring the operating status.
＜Two-stage level switch＞
A level meter installed in a chemical tank. When the liquid level drops to the alarm position, a contact signal is output to the pump and the pump is stopped.
When an alarm relay is attached to the pump, non-voltage contact output linked to the liquid low warning / alarm is possible.

Material

Model name	PPE	PPB	NPE	NPB	PVT	TTT	SST
Pump Head	PP		Acrylic		PVDF	PTFE	SUS316L
Suction valve / Discharge valve	PP		PVC		PVDF	PTFE	SUS316L
O-ring	EPDM	FPM	EPDM	FPM	PTFE
Valve Ball	Ceramic
Chemical solution Example of use	Aluminum sulfate, sodium hydroxide, ferrous sulfate / ferric sulfate	Hydrochloric acid, dilute sulfuric acid, ferric chloride, PAC	Aluminum sulfate, Sodium hydroxide	Sodium hypochlorite, sodium thiosulfate	Hydrochloric acid, sulfuric acid, aqua regia, nitric acid	Concentrated sulfuric acid, hydrofluoric acid, mixed acid	Organic solvent, methanol, acetic acid
