Tohkemy Corporation
Tohkemy Gravity Backwashing Filtration System Water Treatment Systems

Manufacturer: Tohkemy Corporation
Model: Gravity Backwashing Filtration System
Features
Washing tank combined type, save the facility and power expense compared with other filtration equipment.
No need for back wash pump for washing.
No need for keeping capacity for washing water inside the treated water tank, save the installing space.
Fully automatic operation, easy for maintenance.
Applications
Decontamination and filtration of raw water with comparatively less of suspended substances
Iron and manganese removal and filtration
Product Specifications
| Operating Environment | Place of installation | Indoor _or outdoor |
|---|---|---|
| Temperature | 0~40℃ | |
| Raw Water | Water temperature | 0~40℃ (No freezing) |
| Water quality | Turbidity:Not more than 10 degree SS:Not more than 10m/L | |
| General Conditions of Use | Filter material type | Single-layer:Filter sand |
| Filteration velocity | Standard LV10m/h | |
| Max. operating press. | 0.2MPa | |
| Treated Water | Water quality | Turbidity:Not more than 2 degree SS:Not more than 5m/L |
| Backwash Water | Backwash velocity | LV30~40m/h |
Flow Sheet
