YK DS-2CD2186G2-ISU Outdoor Network Camera
Manufacturer: YK Wireless Co., Ltd.
Model: DS-2CD2186G2-ISU
Features
- 8MP resolution for high quality imaging
- Excellent low-light performance with Powered-by-DarkFighter technology
- Efficient H.265+ compression technology
- 120 dB True-WDR technology provides clear images even in strong backlight
- Using deep learning to focus on object classification between people and vehicles
- Equipped with a built-in microphone for real-time audio monitoring
- Audio and alarm terminals available
- Waterproof, dustproof (IP67) and vandal-resistant (IK10)
Specifications
| Camera | |
|---|---|
| Image Sensor | 1/1.8″ Progressive Scan CMOS |
| Shutter Speed | 1/3 sec to 1/100,000 sec |
| Minimum Illumination | Color: 0.003 lux @ (F1.6, AGC ON), B/W: 0 lux with IR |
| Slow Shutter | Supported |
| P/N | P/N |
| Wide Dynamic Range (WDR) | 120 dB |
| Day & Night Function | IR Cut Filter |
| Adjustment Angle | Pan: 0°–355°, Tilt: 0°–75°, Rotation: 0°–355° |
| Lens | |
|---|---|
| Lens Type | Fixed Focal Length Lens, 2.8 mm and 4.0 mm options |
| Focal Length & FOV | 2.8 mm: Horizontal FOV 111°, Vertical FOV 59°, Diagonal FOV 131° |
| 4.0 mm: Horizontal FOV 87°, Vertical FOV 47°, Diagonal FOV 102° | |
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | F1.6 |
| Shooting Distance | 2.8 mm: 2.6 m – ∞ |
| 4.0 mm: 3.2 m – ∞ |
Dimensions
