Deicy M01-CAN CAN Output Pressure Sensor

Manufacturer: DEICY Co., Ltd.
Model: M01-CAN

Features

This is a thin-film measuring element type pressure sensor developed especially for measuring oil pressure in off-highway vehicles.
It outputs digital data internally at a maximum speed of 1000 samples per second via CAN (CANopen/SAEJ1939).

Pressure Range (Gauge Pressure)	0 ~ 10 bar to 0 ~ 1000 bar
Standard Pressure Calibration (bar)	25, 50, 100, 250, 400, 800, 1000
Overload (DIN EN 60770-1) bar	50, 100, 250, 400, 800, 1000
Burst Pressure (DIN EN 60770-1) bar	250, 500, 1000, 2500, 4000
Linearity %FS	< 0.5
Zero Offset Precision	<= 1.5 (0°C ~ +80°C) <= 1.5 (-25°C ~ +100°C) <= 2.5 (-40°C ~ +125°C)
Long-term Stability %FS / year	< 0.2
Measurement Media Temperature Range (°C)	-40 ~ +150 (Cable Out Type -25 ~ +85)
Operating / Storage Temperature Range (°C)	-40 ~ +125 (Cable Out Type -25 ~ +85)
Sampling Rate (samples/sec, max)	1000 samples/sec
Digital Filter	Flat Response
Supply Voltage	9 ~ 35 V DC
CAN / Bus Interface	CANopen / SAE J1939
Electrical Protection	Short Circuit, Signal Ground / VCC Isolation, Reverse Polarity Protection
Electrical Connection Type	M12 Connector DIN-Bayonet (per DIN 72585) DT04-49 Cable Output
Pressure Measurement Connection Type	G 1/4 or 1/4 NPT G 1/4 with manometer 9/16 – 18 UNF (SAE 4) 9/16 – 18 UNF (SAE 6)
Protection Rating	IP 67 or IP 69K (based on electrical connection type)
EMV	EN 61000-6-2 (RF, field 200 V/m, per ISO11452-2) EN 61000-6-4
Shock	20g per IEC 60068-2-27 (Shock mechanical)
Measurement Media Construction Material	DIN 1.4524
Connector Material	DIN 1.4301
