Koganei Shock Absorbers Optional Shock Absorbers For Particular Products
Manufacturer: KOGANEI CORPORATION
Features
Maximize production efficiency with our advanced linear and multi-orifice shock absorbers. Because these units provide effective shock absorption, you can significantly shorten cycle times. Furthermore, the adjustable linear orifice allows for fine-tuning based on impact speed. This design actively prevents equipment damage. Additionally, the silicon-free construction ensures low particle generation to meet JIS ISO Class 5 standards. Since our products offer over 3 million operations, they deliver long-term reliability. Moreover, these components comply with H1 food equipment specifications. Consequently, you can rely on them for high-speed, hygienic environments.
Specifications
Model Item | KSHAX6×5 | KSHAX7×5 | KSHAX8×6 | KSHAX10×8 | KSHAX12×10 |
| Applicable cylinder | XDA□16 | XDA□20 | XDA□25 | XDA□32 | XDA□40 |
| Maximum absorption J [ft·lbf] | 1.5 [1.11] | 2.0 [1.48] | 2.9 [2.14] | 6.9 [5.09] | 11.8 [8.70] |
| Absorbing stroke mm [in.] | 5 [0.20] | 5 [0.20] | 6 [0.24] | 8 [0.31] | 10 [0.39] |
| Maximum impact speed mm/s [ft./sec.] | 700 [2.3] | ||||
| Maximum operating frequency cycle/min | 60 | ||||
| Operating temperature range °C [°F] | 0~60 [32~140] | ||||
| Mass kg [oz.] | 0.018 [0.63] | 0.033 [1.16] | 0.045 [1.59] | 0.084 [2.96] | 0.107 [3.77] |
